    1.0HP Xtreme Dura Non Inverter Wall Mounted Split

    1.0HP Xtreme Dura Non Inverter Wall Mounted Split

    AC001
    MODEL NUMBER: MSXD-09CRN8


    Product Description

    air magicsmart controlprime guardflash cooling
    Indoor unit
    Indoor air flow (H) 580 (341) m³ /h(cfm)
    Indoor Sound level (H/L) 41/30 dB(A)
    Dimension(W*D*H) 835x208x295 mm
    835x208x295 mm 905x355x290 mm
    Net/Gross weight 9.1/11.8 Kg

    Outdoor unit
    Outdoor Sound level 51 dB(A)
    Dimension(W*D*H) 720x270x495 mm
    Packing (W*D*H) 835x300x540 mm
    Net/Gross weight 25/26.8 Kg
    Refrigerant Charge R32/420g
    Design pressure 4.3/1.7 MPa

    Refrigerant piping
    Liquid side/ Gas side mm(inch) Φ6.35/Φ9.52(1/4"/3/8")
    Max. refrigerant pipe length 20 m
    Max. difference in level 8 m

    Misc
    Cooling Capacity 9,200 Btu/h
    Power consumption 772 W
    Running current 3.36 A
    CSPF(Cooling seasonal performance factor) 3.98 Wh/Wh
    Energy Efficiency Star Rating 3
    Power supply 220-240V~,50Hz,1Ph (power supply to indoor) V,Hz,Ph
    Indoor-Outdoor connection wiring (Not included) 3x1.5 mm²
    Power supply wiring(Not included wire) 3x1.5 mm²
    Thermostat type Wireless Remote Control (Wifi control, Wire control optional)
